Vacuum
Trimming Machine |
This machine is designed for trimming U-packings, oil seals, rubber cups,
and soft rubber parts using vacuum-assisted positioning to ensure precision
and stability during trimming. |
| ¡@ |
| ¡@ |
|
Model | PHT - 205 | PHT - 305 | Knife set | 2 | 3 | Knife angle | 0 ~ 90¢X | Shaft speed | 500 ~ 2500 RPM | Trimming range (mm) |
£X10 ~ 120 |
£X120 ~ 200 | Control system |
PLC and air pressure | Capacity |
15 ~ 20 pcs / min | Motor |
2 HP clutch motor |
|
Collect
Chuck Trimming Machine
This machine is specifically designed for trimming both the inner and outer
diameters of oil seals, providing high-precision trimming performance. ¡@ | | ¡@ |
 |
| ¡@ ¡@ ¡@
 | Model | PHT - 405 | PHT - 505 | Knife set | 1 | 2 | Shaft speed | 1000, 1700, 2800 RPM | Trimming range | £X10 ~ 210 mm | Control system | Electric and air pressure | Capacity | 15 ~ 25 pcs / min | Motor | 1.0 KW servo motor | Machine size | L 68 x W 78 x H 160 cm |
¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@ ¡@ |
Square
Ring Cutting Machine | ¡@ ¡@ |
This machine is suitable for cutting square rings after the rubber tube
has been shaped. It offers easy operation and accurate cutting results.
|
| ¡@ |
 |
|
¡@
¡@ |
Model | PHT - 605 | Cutting range |
Outer Dia £X13 ~ 130 mm x L 250 mm x T 20 mm max. | Shaft speed |
1300 / 2500 RPM | Capacity |
30 ~ 40 pcs / min | Control system |
PLC, air pressure and proface touch control | Motor |
1 HP / servo motor 400 W | Machine size |
L 80 x W 12 x H 124 cm |
|
Knife
Grinding Machine | ¡@ |
This machine is used for grinding and sharpening cutting tools used in
rubber, plastic, and PU processing.
The machine is capable of grinding both sharp angles and rounded edges,
depending on the repair needs. It is equipped with a diamond grinding
wheel, making it suitable for sharpening both tungsten carbide and
high-speed steel blades, ensuring fast and efficient operation. It
effectively enhances the sharpness and durability of cutting tools,
improving overall processing efficiency. ¡@ |
| ¡@ ¡@ |
|
|
¡@ ¡@ |
|
Model
|
PHT - 70 |
|
Grinding wheel size |
I.D.1/2 ¡§ x O.D. 150 mm
x Thickness 16 mm |
|
Motor
|
1/4 HP |
|
Grinding angle |
Arc & sharp |
|
Machine size |
L 46 x W 42 x H 110 cm |
¡@
¡@
¡@
¡@
¡@
¡@
¡@
¡@ |
|
